Smart WIFI switch 30A 6.6KW with Energy Monitor / Electrical Power Consumption.

• Current Overload Protection
• Voltage (Over / Under) protection

Used to make any device or appliance that uses a mains input of 230V Smart. Simply, ‘Wire, Configure and Play’. Smart home switch 30A or 6,600 watts.

Typical Applications & Uses

Suitable for farms, small holdings, larger homes or any area where your WiFi range is limited. irrigation, gate or access control, alarm systems. The switch can be connected to a relay to switch even larger currents or even 3 phase pumps etc.

• Mount the switch in a plastic waterproof housing [click here] is preferred. (a steel cabinet for example will reduce the range)
• Your standard garage door and gate remotes are most likely ‘rolling code’ remotes and are NOT compatible with this switch.

Home Automation made Smart, Simple and Affordable via the Tuya, SmartLife App (Android or IOS),  offering the fastest, most stable platform and widest range of Smart Products. Supports Alexa, Google Home and IFTTT.

‘HOW TO’ WIFI SMART YOUTUBE VIDEO [click here] – connect to your cell phone

Product Features

• Small and Compact design – high current. Wire, Configure and Play.
• Power consumption monitor – keep a check on your consumption – energy bills.
• Set a schedule with the multifunction timer: Countdown/Schedule/Circulate/Random/Inching. You can set 1 or more timer to make the boiler turn on/off automatically, or running for a period of time and then close automatically.
• The switch will be turned off automatically to keep safety when the one of following things happens:
  a. Current overload protection >20A (including short circuit)
  b. Voltage over or under protection >265V, or <85V
• Activation dates, days of the week, start time and duration can all be pre-configured via the Smartlife application giving you complete remote control and ON/Off overwrite.
• Supports Voice Commands and also AI units such as Amazon Alexa Echo and Google Home solution.
• All your Smart Devices connected via a Single stable Platform been the Smart Life app from Tuya.
• The entire SmartLife system performance replies on an ‘adequate WIFI’ (2.4GHz only) signal. We recommend the use of our range WIFI Extender products [click here]

Enclosures / Housing

• Need a IP66 Waterproof Enclosure or Housing for the switch? [click here]

Specifications

• Material: ABS Plastic
• Input: AC 85-265V~50/60Hz
• Maximum Load: 30A/6600W
• Internet Connection: IEEE 802.11 b/g/n 2.4GHz
• APP: Tuya Smart & Smart Life
• Certification: CE/FCC/RoHS
• Item Dimensions: 56*93*30mm
• Net Weight: 80g

What’s in the Box?

1x Tuya Smart Switch 30A-P
1x Instruction Manual
